Q777 (Rugged Tablet Andriod/Linux/Window)
Q777 is the latest Saintway’s offering which is specially designed to keep in view the latest market trends. It is an all-in-one rugged detachable, portable, and high-performance vehicle-mounted Mobile Data Terminal that provides an outstanding user experience. Q777 is a 7-inch special, smart, and intelligent mobile data terminal with a bright and daylight viewable TFT-LCD, LED backlight. Moreover, it is equipped with Android 11 OS, lithium-polymer-based high-capacity battery, and Quad-Core A55 ARM processor which results in high-performance prolonged battery backup and low power consumption. In addition to this, various features such as different wireless communication modules, make it the best choice. Taking all these factors into consideration, it can be a perfect companion for a mobile workforce in transportation and logistics.
Q777 7-inch Mobile Data Terminal
● Rugged enclosure design with IP65 rating
● Rockchip RK3568, 2.0GHz
● Android 11 operating system
● Integrated Mali-G52-2EE GPU, up to 800MHz
● Built-in 2.0MP CMOS front camera, 5.0 back camera, built-in stereo speakers
● Built-in WiFi, Bluetooth (4G/3G cellular optional), GPS+GLONASS+BEIDOU
● Built-in and Extended I/O interfaces ACC Input, Reverse Gear Trigger, RS232, RS422/RS485 , AHD Camera In, DC in etc
More Inquiry Video
V7S (Rugged Tablet Andriod/Linux/Window)
Equipping the in-vehicle workforce with digitalization to keep in coordination with their team, could add up to an immense boost in productivity. Saintway recognizes the importance of connectivity to the workers of the vehicle industry. V7S Mobile Data Terminal of Saintway is the technological revolution in the vehicle industry. V7S is an Android-based 7-inch mobile data terminal that is powered by an RK3568 Quad-core Cortex-A55 processor. The newly designed enclosure provides a good ingress protection rating of IP65. With a sunshade hood, it can work in the cab during the daytime. V7S integrates a variety of communication modules such as Wi-Fi, Bluetooth, 4G/3G cellular, and GPS. For more peripheral devices, it has a pigtail cable to meet various I/O ports, like CAN bus, RS232, RJ45, USB OTG, AV, etc.
V7S 7-inch Mobile Data Terminal
● Rugged enclosure design with IP65 rating
● Rockchip RK3568, 2.0GHz
● Android 11 operating system
● Integrated Mali-G52-2EE GPU, up to 800MHz
● Built-in 2.0MP CMOS front camera, built-in stereo speakers(2W,8Ω)
● Built-in 4G/3G cellular, WiFi, Bluetooth, GPS+GLONASS+BEIDOU (optional)
● Built-in and Extended I/O interfaces USB 3.0, TF(up to 128 GB), RJ45, 2x RS232, RS422/485, reverse gear trigger, CAN bus, AV In etc
More Inquiry Video
S8 (Rugged Tablet Andriod/Linux/Window)
S8 is an IP65 grade 8-inch rugged Android tablet that is designed to withstand rough handling, like outdoor or in-vehicle harshest environment use. As for its CPU and OS, the S8 is powered by Rockchip RK3288W ARM Cortex-A17 quad-core with Android 7.1 Nougat system or Linux (Ubuntu18.04). It also integrates optional modules like Gigabit Ethernet for data transmission and NFC for identification. Meanwhile, for in-vehicle use, it has functional interfaces such as RS232, RS422, USB host, etc. which are suitable for many applications such as fleet management, public transit, intelligent mining, precision farming, logistics and industrial control, etc.
S8 8-inch Mobile Data Terminal
● Rugged enclosure design with IP65 rating.
● Rockchip RK3288 Quad-core ARM cortex-A17 processor, 1.8GHz.
● Android 7.1 Nougat operating system.
● Integrated 2D/3D Mali-T764 GPU, up to 600MHz.
● 8-inch 1024×600 LCD with multi-touch capacitive touchscreen.
● Built-in 3.7V 3600mAH Poly-lion battery.
● Built-in 4G cellular, RJ45 Ethernet LAN (Gigabits optional), NFC.
● Extended Cable I/O RS422(RS485 optional), RS232, USB (2 X RS232 optional)
More Inquiry Video
X7R (Rugged Tablet Andriod/Linux/Window)
X7R is a rugged IP54-grade mobile data terminal specifically designed for intelligent transportation like a Fleet Management System. Based on Rockchip RK3368 ARM Cortex- A9 octa-core processor, our X7R has a higher and more reliable performance in-vehicle applications. This device integrates a variety of wireless communication modules such as Wi-Fi, Bluetooth, 4G cellular, and GPS. The rugged enclosure provides more capabilities not only in a wide range of temperatures but also in harsh environments subject to shock and vibration. Its design also allows it to own a good ingress protection rating of IP54. The pigtail cable is designed for more extension data communications, such as RS232, RS422, RJ45, USB, CAN Bus, GPIOs, etc. The X7R works with the Android 6.0 Marshmallow operating system and we provide BSP support for it.
x7r 7-inch Mobile Data Terminal
● Rugged enclosure design with IP54 rating.
● Rockchip RK3368 ARM Cortex-A53 Octa-core processor,1.5GHz.
● Android 6.0 Marshmallow operating system.
● Integrated PowerVR G6110 GPU, Support OpenGL ES 1.1/2.0/3/1
● 7-inch 1024×600 LCD with multi-touch capacitive touchscreen.
● Built-in 4G/3G cellular, RJ45 Ethernet LAN(Gigabits optional), NFC
● Extended Cable I/O RS422(RS485 optional), RS232 , USB( 2 X RS232 optional),CAN Bus
More Inquiry Video
Q77 (Rugged Tablet Andriod/Linux/Window)
Q77 is the latest Saintway’s offering which is specially designed to keep in view the latest market trends. It is an all-in-one rugged detachable, portable, and high-performance vehicle-mounted Mobile Data Terminal that provides an outstanding user experience. Q77 is the 7-inch special, smart, and intelligent mobile data terminal with a bright and daylight viewable TFT-LCD, LED backlight. Moreover, it is equipped with Android 9 OS, a lithium-polymer-based high-capacity battery, and an Octa-core ARM processor which results in high-performance prolonged battery backup and low power consumption. In addition to this, various features such as different wireless communication modules, make it the best choice. Taking all these factors into consideration, it can be a perfect companion for a mobile workforce in transportation and logistics.
Q77 7-inch Mobile Data Terminal
● Rugged enclosure design with IP65 rating
● Qualcomm Octa-core ARM Cortex-A53 processor 1.8GHz
● Android 9.0 operating system
● Integrated Adreno 506 GPU, up to 600MHz
● Built-in 3.7V 5000 mAH Poly-lion battery
● Built-in 2.0MP CMOS front camera, 5.0MP CMOS back camera
● Built-in 4G/3G cellular, GPS+GLONASS+BEIDOU, NFC etc
● Built-in and Extended I/O interfaces USB-Type C, TF(up to 128 GB), POGO PIN, 4xGPIO, OBD|| ,RS232, RS422, RS485, J1939
More Inquiry Video
Q7S (Rugged Tablet Andriod/Linux/Window)
Q7S is the latest Saintway’s offering which is specially designed to keep in view the latest market trends. It is an all-in-one rugged detachable, portable, and high-performance vehicle-mounted Mobile Data Terminal that provides an outstanding user experience. Q7S is the 7-inch special, smart, and intelligent mobile data terminal with a bright and daylight viewable TFT-LCD, LED backlight. Moreover, it is equipped with Android 7.1.2 OS, a Poly-Iion-based high-capacity battery, and a Qualcomm Quad-core processor which results in high-performance prolonged battery backup and low power consumption. In addition to this, various features such as different wireless communication modules, make it the best choice. Taking all these factors into consideration, it can be a perfect companion for a mobile workforce in transportation and logistics.
Q7S 7-inch Mobile Data Terminal
● Rugged enclosure design with IP65 rating
● Qualcomm quad-core 4*ARM Cortex-A7 processor,1.1 GHz
● Android 7.1.2 operating system
● Integrated Adreno 304 GPU, up to 400 MHz
● Built-in 3.7V 5000 mAH Poly-lion battery
● Built-in 2.0MP CMOS front camera, 5.0MP CMOS back camera
● Built-in 4G/3G cellular, GPS+GLONASS+BEIDOU, NFC etc
● Built-in and Extended I/O interfaces USB-Type C, TF(up to 128 GB), POGO PIN, 4xGPIO, OBD|| ,RS232, RS422, RS485, SAE-J1939
More Inquiry Video
V7 (Rugged Tablet Andriod/Linux/Window)
The V7 Mobile Data Terminal by Saintway is a technological revolution in the vehicle industry. It features an Android-based 7-inch display and is powered by a Rockchip PX3 Quad-core ARM Cortex-A9 processor. The newly designed enclosure has an IP65 ingress protection rating and includes a sunshade hood for outdoor use. V7 integrates various communication modules such as Wi-Fi, Bluetooth, 4G/3G cellular, and GPS. It also offers multiple I/O ports, including USB-TypeA, RS232, RJ45, USB, and OTG, to accommodate various peripheral devices.
V7 7-inch Mobile Data Terminal
● Rugged enclosure design with I rating
● Rockchip PX3 Quad-core ARM Cortex-A9, 1.6 GHz
● Android 7.1 operating system
● Integrated 2D/3D Mali-400MP4 GPU, up to 600 MHz
● Built-in 0.3 MP CMOS front camera, built-in stereo speakers(2W,8Ω)x2
● Built-in 4G/3G cellular, WiFi, Bluetooth, GPS+GLONASS+BEIDOU (optional)
● Built-in and Extended I/O interfaces USB Type A, TF(up to 128 GB), RJ45, 2x RS232, OTG
More Inquiry Video
